Blue Sea Circuit Breaker Switch Panel 4 Position - Camo • 4323-BSS
Product Details
4323 Circuit Breaker Switch Panel 4 Position - Camo
- Illuminated 15A Circuit Breakers Provide Switching, “ON” Indication And Overcurrent Protection
- Industry-Standard Sizes And Mounting Allow These Panels To Be Easily Retrofitted In An Existing Application
- Polycarbonate And ABS Panel Surface Is UV-Stabilized, ?ame Retardant, And Will Not Corrode
- Silicon Breaker Boots And Gasket Protects Against Water Ingress
- Low Profile Makes It Easy To Install In Tight Spaces
- Fast-On Circuit Breaker Connectors Make It Quick To Wire
- Two-Wire Connection For Powering All Panels Is Simple And Requires 10 Ring Terminals, Terminals Screw To Bus Bars For Secure Connections
- Set of 15 square format circuit labels are included, and are easy to replace. Additional standard or custom labels are available through Blue Sea System
- Color: Camo
- Positions: 4
- Nominal Voltage: 12 VDC
- Maximum Amperage: 45A
- Terminal Type: 1/4" Male Quick Connect
- Hardware: Stainless Steel #6 x 5/8" mounting screws
- Ring Terminal Size: M5 (#10)
$36.99
Only 1 left in stock - order soon
Quantity
