SI-TEX NavPro 1200C GPS Chart Plotter Series • NAVPRO900US

The NavPro 1200 MFD offers optional high-resolution WI-FI radar that makes it easy to install and rig SI-TEX’s 4 Kilowatt, 24-Inch compact radome on just about any vessel. By mounting and wirelessly syncing the SI-TEX MDS-12 Network Radome to a NavPro unit, boaters can turn these popular and affordable MFDs into powerful 36-Newtonmeter range radars that deliver excellent target resolution and a range of features boaters expect from professional-grade SI-TEX radars. Overlaying radar targets onto the feature-rich Polaris Charts provides navigators with enhanced situational awareness and safety, even in the most challenging conditions.

---

• 12” Hi-Res. Hybrid Touch Screen Display
• Heavy Duty Yoke mount for Bulkhead or Overhead Mounting
• NMEA-0183 & NMEA2000 Interfacing
• WIFI Interface
• Automatic Software Updates when in WIFI Coverage
• Captain Cloud automatically backs up all User Data to a Free Cloud Based Data backup Service for Waypoints, Marks, Events, and Track memories when in WIFI coverage.
• Mirror Screen Capability via Bluetooth connection allows user to download mirror app to his Android based smart phone and view and control the NavPro 900 from Smart Phone.
• Optional dedicated Remote Control Available
• Designed for easy flush mount without any special kit needed
• New CHIRP Sounder with selectable 300w, 600w, & 1kW outputs (NavPro-900F version)
• CHIRP Sounder has scroll back screen memory that allows user to quickly scroll back and pickoff a location to mark on Nav Chart.
• Uses the popular AIrmar CHIRP Transducers with TX ID will automatically setup the Sounder transducer interconnect
• Adapters available to allow the unit to be installed on older non-CHIRP transducers
• Internal Hi-Resolution 18Hz 72 Channel GPS Receiver & Antenna

• New User interface makes the unit very easy to operate and navigate with
• Full AIS Integration when interfaced to an AIS Unit

---

SPECIFICATIONS

• LCD Display Size 12.0”
• Display Brightness 1250 NITS
• Display Resolution 1024x768
• Touch Screen – Yes, Capacitive Multi-Touch
• Keyboard Backlight – Yes
• Operating Voltage 10 to 35 VDC
• GPS Receiver – Built-In High Resolution 18Hz 72 Channel
• GPS/GLONASS
• External GPS – Yes, optional via 6 pin Connector
• Network Connections – NMEA-2000 (Optional Cable Required)
• Dual NMEA-0183 Input/Output Ports
• WIFI Connection – Yes
• Bluetooth Connection – Yes
• IPX6 Waterproof Rating
• Operating Temperature range -10’C to +60’C
• Dimensions – 15.3” Wide x 10.9” High x 5.8” Deep
• 2 Year Warranty

---

INCLUDED IN THE PACKAGE:

• NavPro 1200C Display Unit
• Polaris USA Chart Card
• Mounting Bracket
• Mounting Screws
• Combination Power Data Cord
• Sun Cover
• Installation & Operation manual
