Sierra 3 Position Ignition Switch • MP39200

Sierra's 3-Position Ignition Switch fits a standard 7/8"dia. hole and includes a snap-on rubber cap for additional protection from mist or spray. Nickel-silver screw terminals ensure long-lasting conductivity. This three-position conventional switch provides Off-Run-Start with three terminals. Includes two keys and different key codes for added security.

• Maximum corrosion protection eliminates oxidation
• Inner seal between cylinder lock and contact plate
• Non-conductive housing eliminates potential shorts
• Three-position conventional switch
• Interchangeable with Cole-Hersee M850BP and Seadog 420365-1

Specifications:

• Material: Marine-grade glass-filled polyester
• Length: Long, 1 1/8" maximum panel thickness
• Hole Size: 7/8"
• Terminal Type: 3 screw tab
• Back Up Nut: Brass
• Face Nut: Knurled black plastic with snap-on rubber cap
• Positions: Off-Run-Start

Rated:

• Ignition: 15A @ 12V DC
• Solenoid: 30A @ 12V DC
