Sierra 3-Position Ignition Switch with Choke • MP39760

Sierra's Polyester Marine Ignition Switch fits a standard 7/8"dia. hole and offers impact and corrosion protection. Nickel-silver screw terminals ensure long-lasting conductivity. This three-position magneto switch provides Off-Run-Start with push-to-choke. Includes two keys and different key codes for added security.

• Maximum corrosion protection eliminates oxidation
• Inner seal between cylinder lock and contact plate
• Non-conductive housing eliminates potential shorts
• Three-position magneto switch
• Convenient push-to-choke

• Material: Marine-grade glass-filled polyester
• Length: Short, 5/8" maximum panel thickness
• Hole Size: 7/8"
• Terminal Type: 5 screw tab, 1 boss screw
• Back Up Nut: Plastic
• Face Nut: Hex black plastic
• Choke: Push-to-choke
• Positions: Off-Run-Start

• Ignition: 15A @ 12V DC
• Solenoid: 30A @ 12V DC
• Choke: 7A @ 12V DC
