Sierra 3-Position Ignition Switch with Choke • MP41000

Sierra Marine's replacement engine components are manufactured to meet or exceed OEM requirements. This ignition switch provides maximum corrosion protection and features a non-conductive housing that eliminates potential shorts. It also features an inner seal between the cylinder lock and contact plate.

Specifications:

• Push to choke
• Back up nut: Brass
• Face nut: Hex black plastic
• Hole Size: 7/8"
• Length: Short 5/8" maximum panel thickness
• Material: Marine-grade glass-filled polyester
• Rated Choke: 7 Amp @ 12 VDC
• Rated Ignition: 15 Amp @ 12 VDC
• Rated Solenoid: 30 Amp @ 12 VDC
• Terminal Type: 6 Screw tab
• Switch Positions: Off - Run - Start

Interchangeable with:

• Mercury Marine
• 87-17393
• 87-88107
• 87-88107A5
• Mercury Sport Jet
• 87-88107
• 87-88107A5
• Seadog
• 420381-1
