Simrad XSonic Airmar SS75H Transducer 12° Tilt • 000-13912-001

Perfect for smaller boats up to 8 Meter, this stainless steel through hull mounted CHIRP transducer enables bottom detection down to 3,000 Meter with great detail and resolution. This transducer makes it possible to distinguish between individual baitfish, game fish and underwater structures.

---

• Mounting Location: Thru-Hull Mount
• Number Of Pins: 9 Pin
• Depth: 10000 Feet
• Power Rating: 600 Watt
• Frequency Range: 130-210 kHz High Frequency CHIRP Transducer
• Supported Angle: 12 Degree Tilt/ 8 To 15 Degree Deadrise
• Cable Length: 33 Feet
• Calculates How Deep The Water Is
• Temperature Sensor For Accurate Water Temperature Readings
• CHIRP Range Is 130 Kilohertz To 210 Kilohertz For Good Target Detail In Shallow Water And Excellent Bottom Tracking In Deep Water
• Low Profile Housing Minimizes Drag With Just 5mm Extending Outside Of The Hull
• 12 Degree Tilt Is Ideal For Boats With A 8 Degree To 15 Degree Hull Deadrise
• Limited 2 Year Warranty
