T-H Marine Atlas 8" Setback Polished Hydraulic Jack Plate • AHJ-8V-DP

The ATLAS Hydraulic Jack Plate by T-H Marine is truly the next generation in jack plate design. Built for the heaviest and most powerful outboard engines on the market today, even the big four strokes. Our innovative, high-tech engineered polymer rod and slot-lifting design guarantees you trouble free action. This jack plate also features the newest concept in one-piece hydraulics from the most respected name in hydraulic design.

• Bottom To Top In Less Than 8 Seconds Rod And Slot Lifting Design
• Trouble Free Lifting Action Hi-Tech Engineered Polymer Rods
• Speed And Self-Contained Lifting Action
• Comes With Relay Harness And Rocker Switch
• Limited Lifetime Frame And 3 Year Structural Warranty

• Adjustment Type: Hydraulic
• Maximum Horsepower: 300 Horsepower
• Mounting Position Adjustment: Not Applicable
• Rise Time: 8 Seconds
• Weight Capacity: 625 Pounds
• Setback: 8 Inch
• Hydraulic Rise: 5-3/4 Inch
• Total Rise: 8-1/4 Inch To 9-3/4 Inch
• Finish: Polished
• Color: Silver
• Material: Aluminum
• With Rocker Switch: Yes
• With Relay Harness: Yes
